Cisco 300-420 Online Practice Questions and Exam Preparation

Cisco 300-420 Online Questions & Answers

• Question 221:

  An architect is designing a multicast solution for a network that contains over 100 routers. The architect plans to create several multicast domains and balance the PIM-SM traffic within the network. Which technology should the architect include in the design?

  A. DVMRP
  B. IGMP
  C. MOSPF
  D. MSDP
  D. MSDP

• Question 222:

  Which three ways are SD-Access and ACI Fabric similar? (Choose three.)

  A. use of Virtual Network IDs
  B. use of Endpoint Groups
  C. use of group policy
  D. use of Scalable Group Tags
  E. focus on user endpoints
  F. use of overlays
  A. use of Virtual Network IDs
  D. use of Scalable Group Tags
  F. use of overlays

• Question 223:

  How is end-to-end microsegmentation enforced in a Cisco SD-Access architecture?

  A. VLANs are used to segment traffic at Layer 2.
  B. 5-tuples and ACLs are used to permit or deny traffic.
  C. SGTs and SGTACLs are used to control access to various resources.
  D. VRFs are used to segment traffic at Layer 3.
  C. SGTs and SGTACLs are used to control access to various resources.

• Question 224:

  An engineer uses Postman and YANG to configure a router with:

  3.OSPF process ID 200

  4.network 172.16.10.128/26 enabled for Area 0

  Which get-config reply verifies that the model set was designed correctly?





  A. Option A
  B. Option B
  C. Option C
  D. Option D
  A. Option A

• Question 225:

  Refer to the exhibit.



  An engineer is designing an OSPF solution with these requirements:

  1.NMS server will manage R5 and R6.

  2.Upon failure of R1, all NMS traffic should be routed through R4.

  3.Upon failure of the link between R5 and R6, all traffic destined for 10.6.6.6 should be routed through R4. Which solution must the engineer choose?

  A. Redistribute OSPF process 1 into process 2 on R1 and R4.
  B. Advertise 172.16.1.1 into OSPF process 1 with high cost on R1.
  C. Apply static routes on R2 and R3 with IP SLA tracking toward R5 and R6.
  D. Enable the default-information originate command with a higher metric on R2 to R1.
  A. Redistribute OSPF process 1 into process 2 on R1 and R4.

• Question 226:

  What are two purposes of the RPF check in multicast routing? (Choose two.)

  A. to ensure that multicast packets are forwarded if they arrived on the interface used to route traffic back to the source address
  B. to ensure that multicast packets are forwarded if they arrived on the interface used to route traffic to the destination address
  C. to ensure that multicast packets are dropped if they arrived on the interface used to route traffic to the destination address
  D. to ensure that multicast packets are dropped if they arrived on the interface used to route traffic back to the source address
  E. to ensure that multicast packets, no matter the interface they arrived on are forwarded out all interfaces
  A. to ensure that multicast packets are forwarded if they arrived on the interface used to route traffic back to the source address
  C. to ensure that multicast packets are dropped if they arrived on the interface used to route traffic to the destination address

• Question 227:

  Which two options are primary functions of Cisco ISE? (Choose two.)

  A. enforcing endpoint compliance with network security policies
  B. enabling WAN deployment over any type of connection
  C. automatically enabling, disabling or reducing allocated power to certain devices
  D. providing information about every device that touches the network
  E. providing encryption for any type of mobile devices
  F. allocating cloud resources
  A. enforcing endpoint compliance with network security policies
  D. providing information about every device that touches the network

• Question 228:

  What is the main purpose of the Cisco SD-Access underlay design?

  A. to enable automated network provisioning and configuration
  B. to provide network segmentation and isolation for security
  C. to support advanced firewall and IPS features
  D. to optimize network traffic routing and load-balancing
  D. to optimize network traffic routing and load-balancing

• Question 229:

  What is the purpose of a TLOC extension in a Cisco SD-WAN network fabric?

  A. to facilitate WAN Edge router redundancy within a site
  B. to identify the physical interface where a WAN Edge router connects to the WAN transport network
  C. to expand the number of colors that are potentially applied to a network transport interface
  D. to aggregate multiple physical interfacesinto a single logical Interface
  A. to facilitate WAN Edge router redundancy within a site

• Question 230:

  Which two statements are true regarding Cisco ISE? (Choose two.)

  A. The number of logs that ISE can retain is determined by your disk space
  B. ISE supports IPv6 downloadable ACLs
  C. In two-node standalone ISE deployments, failover must be done manually
  D. ISE supports up to 100 Policy Services Nodes
  E. ISE can detected endpoints whose addresses have been translated via NAT
  F. In distributed deployments, failover from primary to secondary Policy Administration Nodes happens automatically
  A. The number of logs that ISE can retain is determined by your disk space
