Cisco 300-420 Online Practice Questions and Exam Preparation

Cisco 300-420 Online Questions & Answers

• Question 181:

  When IPsec VPNs are designed, what is a unique requirement if support for IP Multicast is required?

  A. encapsulation of traffic with GRE or VTI
  B. IPsec forwarding using transport mode
  C. additional bandwidth for headend
  D. IPsec forwarding using tunnel mode
  A. encapsulation of traffic with GRE or VTI

• Question 182:

  Refer to the exhibit. Which two solutions maximize the use of the links between the core and distribution layers? (Choose two.)



  A. use multiple equal-cost links
  B. use an IGP
  C. use HSRP
  D. use RPVSTP+
  E. use multiple unequal-cost links
  A. use multiple equal-cost links
  B. use an IGP

• Question 183:

  Refer to the exhibit.



  An engineer Is designing a multicampus Layer 3 Infrastructure using EIGRP as the routing protocol. The design must provide quick replies to queries. In the event of a downlink, prevent unnecessary queries, and ensure that traffic does not unnecessarily transit the access layer.

  Which two actions must the engineer take for the network design? (Choose two.)

  A. Configure core layer switches as stub routers.
  B. Configure distribution layer switches to summarize routes to the core layer.
  C. Configure access layer switches as stub routers.
  D. Configure access layer and core layer switches as stub routers.
  E. Configure access layer switches to summarize routes to the distribution layer.
  B. Configure distribution layer switches to summarize routes to the core layer.
  C. Configure access layer switches as stub routers.

• Question 184:

  Which method will filter routes between EIGRP neighbors within the same autonomous system?

  A. distribute-list
  B. policy-based routing
  C. leak-map
  D. route tagging
  A. distribute-list

• Question 185:

  Refer to the exhibit.



  A customer is running HSRP on the core routers. Over time the company has grown and requires more network capacity. In the current environment, some of the downstream interfaces are almost fully utilized, but others are not. Which solution improves the situation?

  A. Make router R2 active for half of the VLANs.
  B. Add more interfaces to R1 and R2.
  C. Configure port channel toward downstream switches.
  D. Enable RSTP on the downstream switches.
  A. Make router R2 active for half of the VLANs.

• Question 186:

  How is redundancy achieved among Cisco vBond Orchestrators in a Cisco SD-WAN deployment?

  A. The IP addresses of all Orchestrators are mapped to a single DNS name.
  B. The closest Orchestrator to each Cisco WAN Edge router is selected.
  C. Cisco WAN Edge routers are configured with all Orchestrators using their IP addresses and priority.
  D. A single Cisco Orchestrator is deployed in each network.
  A. The IP addresses of all Orchestrators are mapped to a single DNS name.

• Question 187:

  Refer to the exhibit



  An engineer working for a telecommunication company with an employee ID 4449:30 959 Is calculating STP scalability for switches to ensure that the numbers are below the maximum supported value for STP logical ports

  How many logical interfaces are active for switch A?

  A. 4
  B. 307
  C. 202
  D. 100
  C. 202

• Question 188:

  A company needs to increase access port capacity on one floor of a building. They want to leverage the existing catalyst access switch. There is no problem with uplink bandwidth capacity. However, no additional uplinks can be added because no ports are available on the distribution switches. Which solution must the company choose to provide additional access ports?

  A. VDC
  B. VSS
  C. Etherchannel
  D. Stackwise
  D. Stackwise

• Question 189:

  A company is planning to open two new branches and allocate the 2a01:c30:16:7009::3800/118 IPv6 network for the region. Each branch should have the capacity to accommodate a maximum of 200 hosts. Which two networks should the company use? (Choose two.)

  A. 2a01:0c30:0016:7009::3a00/120
  B. 2a01:0c30:0016:7009::3b00/121
  C. 2a01:0c30:0016:7009::3a80/121
  D. 2a01:0c30:0016:7009::3c00/120
  E. 2a01:0c30:0016:7009::3b00/120
  A. 2a01:0c30:0016:7009::3a00/120
  E. 2a01:0c30:0016:7009::3b00/120

• Question 190:

  What is an advantage of using model-driven telemetry in the network?

  A. It uses interrupt-driven polling to pull data at regular intervals.
  B. It uses MIB models to structure the data that are well known in the industry.
  C. It uses JSON encoding and is compatible with a wide variety of tools on the market.
  D. Telemetry obtains data by parsing the CLI output from show commands.
  C. It uses JSON encoding and is compatible with a wide variety of tools on the market.
