F5 101 Online Practice Questions and Exam Preparation

F5 101 Online Questions & Answers

• Question 471:

  A BIG IP Administrator reviews the Virtual Server configuration and sees the object status represented by a blue square tor an unknown status. How should the administrator change the unknown status?

  A. restart the BIG-IP device
  B. assign a monitor to the pool
  C. restart the backend webserver
  D. run a packet capture on the BIG-IP device
  B. assign a monitor to the pool

• Question 472:

  What is the correct procedure to comply with the recommendation?



  A. Download the product version image from ihealth f5 com
  B. Download the product version image from support 6 com
  C. Download the product version image from dovcentral f5.com
  D. Download the product version image from downloads f5.com
  D. Download the product version image from downloads f5.com

• Question 473:

  A BIG-IP has a virtual server at 150.150.10.10:80 with SNAT automap configured. This BIG-IP also has a SNAT at 150.150.10.11 set for a source address range of 200.200.1.0 / 255.255.255.0. All other settings are at their default states. If a client with the IP address 200.200.1.1 sends a request to the virtual server, what is the source IP address when the associated packet is sent to the pool member?

  A. 200.200.1.1
  B. 150.150.10.11
  C. Floating self IP address on VLAN where the packet leaves the system
  D. Floating self IP address on VLAN where the packet arrives on the system
  C. Floating self IP address on VLAN where the packet leaves the system

• Question 474:

  If there are multiple applications authenticated against a single identity store, which technology solution will simplify access to all applications?

  A. RADIUS
  B. single sign on
  C. multifactor authentication
  D. LDAP
  B. single sign on

• Question 475:

  When using a single BIG-IP with APM, an organization can support up to 60,000 concurrent remote access users.

  A. True
  B. False
  A. True

• Question 476:

  Assuming that systems are synchronized, which action could take place if the failover cable is connected correctly and working properly, but the systems cannot communicate over the network due to extern al network problems.

  A. If network failover is enabled, the standby system will assume the active mode.
  B. Whether or not network failover is enabled, the standby system will stay in standby mode.
  C. Whether or not network failover is enabled, the standby system will assume the active mode.
  D. If network failover is enabled, the standby system will go into active mode but only until the network recovers.
  B. Whether or not network failover is enabled, the standby system will stay in standby mode.

• Question 477:

  Which three must be done so that Generic Host Servers can be monitored using SNMP? (Choose three.)

  A. The SNMP monitor must be added to all BIG-IP Systems.
  B. The Generic Host Server must be running the big3d agent.
  C. The GTM System must be configured for the appropriate MIB.
  D. The Generic Host Server must be added to the GTM Configuration.
  E. The Generic Host Server must be enabled to answer SNMP queries.
  C. The GTM System must be configured for the appropriate MIB.
  D. The Generic Host Server must be added to the GTM Configuration.
  E. The Generic Host Server must be enabled to answer SNMP queries.

• Question 478:

  GTM can load balance to LTM in addition to non-BIG-IP hosts.

  A. True B. False
  A. True B. False

• Question 479:

  A company would like to create a web service for multiple data centers (US EU, ASia) where each data center uses the same IP address Requests will be routed to the closest data center. Which address type is the appropriate solution?

  A. Broadcast
  B. Unicast
  C. Anycast
  D. Micest
  C. Anycast

• Question 480:

  Which four of the following items are physical objects used by GTM?

  A. Virtual servers
  B. Links
  C. Servers
  D. Wide IPs
  E. Data centers
  F. Pools
  A. Virtual servers
  B. Links
  C. Servers
  E. Data centers
