Huawei Huawei Certification H12-211 Questions & Answers

• Question 31:

  According to the topology and configuration of interconnected interfaces of switches shown in the figure, the data frame tagged with VLAN 10 can be forwarded correctly between the two switches.



  A. True

  B. False

  Correct Answer: A

• Question 32:

  The network administrator creates VLAN 10 and assigns an IP address to VLANIF10. When using the command "display ip interface brief", the administrator finds that VLANIF10 is down. What should be done to enable VLANIF10?

  A. Use the command "undo shutdown" under the interface view for VLANIF10

  B. Assign a physical interface that has either an active of inactive physical state to VLAN 10

  C. Assign only a physical interface that has an active physical state to VLAN 10

  D. Add an interface that has an active physical state and a trunk port associated with VLAN 10

  Correct Answer: C

• Question 33:

  A network administrator wishes to implement VLAN 10 to isolate certain users. It is common however for these users to often change their physical location. Which of the following VLAN implementations should be used?

  A. Port based VLAN assignment

  B. Protocol based VLAN assignment

  C. MAC based VLAN assignment

  D. IP subnet based VLAN assignment

  Correct Answer: C

• Question 34:

  On the VRP, what is the function of the "interface vlanif " command?

  A. It is used to create a VLANIF interface

  B. It is used to create a VLANIF interface and enter the VLANIF interface view

  C. It is used to configure a VLAN for a VLANIF interface

  D. There is no such command

  Correct Answer: B

• Question 35:

  Refer to the graphic.



  Both switches are operating using STP. With exception to those shown, all other default parameters have been maintained. Which port will be blocked?

  A. Port G0/0/1 of switch A.

  B. Port G0/0/2 of switch B.

  C. Port G0/0/1 of switch B.

  D. Port G0/0/2 of switch A.

  Correct Answer: C

• Question 36:

  Layer 2 switches are data link layer devices that identify MAC addresses of Layer 2 data frames and forward Layer 2 data frames based on MAC addresses. In addition, they record mappings between MAC addresses and interfaces in the MAC address table.

  A. True

  B. False

  Correct Answer: A

• Question 37:

  In RSTP mode, both alternate and backup ports cannot forward user traffic but can receive, process, and send BPDU.

  A. True

  B. False

  Correct Answer: A

• Question 38:

  Refer to the graphic.



  The switch is operating using STP. All default parameters have been maintained. Which port will be assigned a designated port role?

  A. G0/0/1 of switch A.

  B. G0/0/2 of switch A.

  C. E0/0/1 of the hub.

  D. E0/0/2 of the hub.

  Correct Answer: A

• Question 39:

  How can the default route be generated? (Choose all that apply.)

  A. Manually configured.

  B. Automatically generated by the router.

  C. Generated by dynamic routing protocols.

  D. Generated by link layer protocols.

  Correct Answer: AC

• Question 40:

  Refer to the graphic.



  The routing table includes direct routes and static routes and the preference of the direct routes cannot be changed.

  A. True

  B. False

  Correct Answer: A
